1、配電柜常見的燒損故障
1. Common burning failure of distribution cabinet
母線鋁觸頭燒損、配電柜并聯漏電斷路器或開路燒損、配電柜下端RTO熔絲燃燒損失、配電柜低壓儀表、出風口或避雷器燒壞、配電柜設備接觸螺釘擰緊不牢固發熱排出、配電柜內部短路。
Burning loss of aluminum contact of bus, parallel leakage circuit breaker or open circuit of distribution cabinet, burning loss of RTO fuse at the lower end of distribution cabinet, burning loss of low-voltage instrument, air outlet or arrester of distribution cabinet, loose tightening of contact screw of equipment of distribution cabinet, heat discharge, internal short circuit of distribution cabinet.
2、管理原因燒損
2. Management cause burning
因為之間的短路線路在接收端,漏電保護或怠速運轉電流超過額定電流使保護或閑置或空鉛和終端點燃，燃燒的配電箱。
Because of the short circuit between the lines at the receiving end, leakage protection or idle running current exceeds the rated current, making the protection or idle or empty lead and the terminal ignite, burning the distribution box.
出線配電室是四級線與T低壓出口鋼管,標準的u型防水彎不了,導致雨水倒漏電保護器，當負荷過大或過流時，加熱器會被加熱，造成著火燒損。
The outgoing line distribution room is a class IV line and t low-voltage outlet steel pipe. The standard U-shaped waterproof can not be bent, which leads to rainwater leakage protector. When the load is too large or the current is too high, the heater will be heated, causing fire damage.
雷暴天氣時，農村配電室配電柜低壓避雷器因雷擊電流過大發生故障，導致避雷器引燃，導致配電柜儀表引線著火，損壞配電柜。并且接地線不合格或者沒有，檢察人員也有沒檢查到，導致雷電天氣引發燒損，這是主要的原因之一。
In thunderstorm weather, the low-voltage arrester of the distribution cabinet in rural distribution room fails due to excessive lightning current, which leads to the ignition of the arrester, the ignition of the instrument lead of the distribution cabinet and the damage of the distribution cabinet. And the ground wire is not qualified or not, prosecutors have not checked, leading to lightning weather caused by burning, which is one of the main reasons.
3、技術原因燒損
3. Burning loss due to technical reasons
配電柜容量不合理過小，導致配電設備過載、過載時電氣設備燃燒。配電柜防雷設施不完善。，簡單的配電柜沒有配備低壓避雷器。二是配電柜未按照低壓電網技術規范可靠接地。
The unreasonable capacity of distribution cabinet is too small, which leads to the overload of distribution equipment and the combustion of electrical equipment when it is overloaded. The lightning protection facilities of distribution cabinet are not perfect. First of all, the simple distribution cabinet is not equipped with low-voltage arrester. Second, the distribution cabinet is not grounded safely and reliably according to the technical specification of low voltage power grid.
